sudo dnf install -y nmap-ncat

for tgt in <oracdb1-ip> <oracdb2-ip> <oradg-obs-ip>; do
  nc -zv -w 5 "$tgt" 22
  nc -zv -w 5 "$tgt" 1521
done

# Run on each VM, substituting the local short name (oracdb1, oracdb2, oradg-obs)
sudo hostnamectl set-hostname <this-host>.example.internal

# Run on every VM (same content)
sudo tee -a /etc/hosts >/dev/null <<EOF

# Oracle DG peers + FSFO Observer
<oracdb1-ip>    oracdb1.example.internal    oracdb1
<oracdb2-ip>    oracdb2.example.internal    oracdb2
<oradg-obs-ip>  oradg-obs.example.internal  oradg-obs
EOF

ping -c 1 oracdb1 && ping -c 1 oracdb2 && ping -c 1 oradg-obs

# Oracle 26ai preinstall (package name varies by repo)
sudo dnf install -y oracle-ai-database-preinstall-26ai \
  || sudo dnf install -y oracle-database-preinstall-26ai \
  || sudo dnf install -y oracle-database-preinstall-23ai

# grid user + asm groups
sudo groupadd -g 54327 asmadmin; sudo groupadd -g 54328 asmdba; sudo groupadd -g 54329 asmoper
sudo useradd -u 54322 -g oinstall -G dba,oper,asmadmin,asmdba,asmoper grid
sudo passwd -l grid; sudo passwd -l oracle
sudo usermod -a -G asmdba,asmadmin oracle

# iSCSI, multipath, OUI JDK
sudo dnf install -y iscsi-initiator-utils device-mapper-multipath sg3_utils \
  java-21-openjdk-headless libxcrypt-compat

# THP and time
cat /sys/kernel/mm/transparent_hugepage/enabled   # expect [never]
timedatectl
chronyc tracking

sudo setenforce 0
sudo sed -i 's/^SELINUX=.*/SELINUX=permissive/' /etc/selinux/config
sudo systemctl disable --now firewalld

sudo cp -n /etc/iscsi/iscsid.conf /etc/iscsi/iscsid.conf.orig
sudo sed -i '/^[#[:space:]]*node\.session\.timeo\.replacement_timeout/d' /etc/iscsi/iscsid.conf
echo "node.session.timeo.replacement_timeout = 120" | sudo tee -a /etc/iscsi/iscsid.conf
sudo systemctl enable --now iscsid

sudo reboot

sudo cat /etc/iscsi/initiatorname.iscsi
# InitiatorName=iqn.1994-05.com.redhat:abc123def456

sudo iscsiadm --mode session
sudo multipath -ll

sudo tee /etc/multipath.conf >/dev/null <<'EOF'
defaults {
    find_multipaths     yes
    user_friendly_names yes
}
blacklist {
    devnode "^(ram|raw|loop|fd|md|dm-|sr|scd|st)[0-9]*"
    devnode "^hd[a-z]"
    devnode "^cciss.*"
}
EOF
+
sudo systemctl enable --now multipathd
sudo multipath -ll

multipaths {
    multipath { wwid <host-discovered-wwid-for-u01>      alias ora_oracdb1_u01     }
    multipath { wwid <host-discovered-wwid-for-data-01>  alias ora_oracdb1_data_01 }
    multipath { wwid <host-discovered-wwid-for-data-02>  alias ora_oracdb1_data_02 }
    multipath { wwid <host-discovered-wwid-for-arch-01>  alias ora_oracdb1_arch_01 }
    multipath { wwid <host-discovered-wwid-for-fra-01>   alias ora_oracdb1_fra_01  }
}

sudo systemctl restart multipathd
ls -l /dev/mapper/ora_$(hostname -s)_*

HOST=$(hostname -s)        # oracdb1 on the primary, oracdb2 on the standby
for dev in /dev/mapper/ora_${HOST}_data_01 \
           /dev/mapper/ora_${HOST}_data_02 \
           /dev/mapper/ora_${HOST}_arch_01 \
           /dev/mapper/ora_${HOST}_fra_01; do
  sudo parted -s "$dev" mklabel gpt
  sudo parted -s "$dev" mkpart primary 0% 100%
done
sudo partprobe
sudo systemctl reload multipathd
ls /dev/mapper/ora_${HOST}_*p1     # expect 4 partitions

HOST=$(hostname -s)
sudo tee /etc/udev/rules.d/99-oracle-asm.rules >/dev/null <<'EOF'
KERNEL=="dm-*", ENV{DM_UUID}=="part?-mpath-*", ENV{DM_NAME}=="ora_oracdb*_*p?", \
    OWNER="grid", GROUP="asmadmin", MODE="0660"
EOF

sudo udevadm control --reload-rules
for part in /dev/mapper/ora_${HOST}_*p1; do
  dm=$(readlink -f "$part" | xargs basename)
  sudo udevadm trigger --action=change --name-match="/dev/${dm}"
done
sudo udevadm settle
ls -lL /dev/mapper/ora_${HOST}_*p1    # grid:asmadmin 0660

HOST=$(hostname -s)
U01_DEV=/dev/mapper/ora_${HOST}_u01
ls -l "$U01_DEV"

sudo mkfs.xfs -f "$U01_DEV"
U01_UUID=$(sudo blkid -s UUID -o value "$U01_DEV")

sudo mkdir -p /u01
echo "UUID=${U01_UUID} /u01 xfs defaults,_netdev,nofail,x-systemd.requires=iscsi.service,x-systemd.requires=multipathd.service,x-systemd.after=iscsi.service,x-systemd.after=multipathd.service 0 0" | sudo tee -a /etc/fstab
sudo mount -a

sudo mkdir -p /u01/app/oraInventory /u01/app/26ai/grid /u01/app/grid \
  /u01/app/oracle/product/26ai/db_1 /u01/stage
sudo chown -R grid:oinstall /u01/app/oraInventory /u01/app/26ai /u01/app/grid
sudo chown -R oracle:oinstall /u01/app/oracle /u01/stage
sudo chmod -R 775 /u01/app /u01/stage

sudo su - oracle
. ~/.bash_profile        # ORACLE_SID=orcl, ORACLE_HOME set

GRID_HOME=/u01/app/26ai/grid
sudo -u grid tee "$GRID_HOME/network/admin/listener.ora" >/dev/null <<'EOF'
LISTENER =
  (DESCRIPTION =
    (ADDRESS = (PROTOCOL = TCP)(HOST = oracdb2.example.internal)(PORT = 1521)))

SID_LIST_LISTENER =
  (SID_LIST =
    (SID_DESC = (GLOBAL_DBNAME = orcls)        (ORACLE_HOME = /u01/app/oracle/product/26ai/db_1) (SID_NAME = orcls))
    (SID_DESC = (GLOBAL_DBNAME = orcls_DGMGRL) (ORACLE_HOME = /u01/app/oracle/product/26ai/db_1) (SID_NAME = orcls)))
EOF

sudo -u grid bash -c '
export GRID_HOME=/u01/app/26ai/grid
export ORACLE_HOME=$GRID_HOME
$GRID_HOME/bin/srvctl stop listener
$GRID_HOME/bin/srvctl start listener
$GRID_HOME/bin/lsnrctl status
'

PRIMARY_ZONE=us-west1-a       # zone of oracdb1
STANDBY_ZONE=us-west1-b       # zone of oracdb2

gcloud compute scp \
  oracdb1:/u01/app/oracle/product/26ai/db_1/dbs/orapworcl ./orapworcl \
  --zone=$PRIMARY_ZONE --tunnel-through-iap

gcloud compute scp \
  ./orapworcl oracdb2:/u01/app/oracle/product/26ai/db_1/dbs/orapworcls \
  --zone=$STANDBY_ZONE --tunnel-through-iap

# On oracdb1
sudo -u oracle sqlplus -s / as sysdba \
  <<<"SELECT value FROM v\$parameter WHERE name='compatible';"

sudo -u oracle mkdir -p /u01/app/oracle/admin/orcls/adump
sudo chown oracle:oinstall /u01/app/oracle/product/26ai/db_1/dbs/orapworcls
sudo chmod 0600 /u01/app/oracle/product/26ai/db_1/dbs/orapworcls

sudo -u oracle tee /u01/app/oracle/product/26ai/db_1/dbs/initorcls.ora >/dev/null <<'EOF'
*.db_name='orcl'
*.db_unique_name='orcls'
*.audit_file_dest='/u01/app/oracle/admin/orcls/adump'
*.diagnostic_dest='/u01/app/oracle'
*.compatible='<COPY_FROM_PRIMARY>'
*.sga_target=3072m
*.pga_aggregate_target=1024m
*.processes=320
*.remote_login_passwordfile='EXCLUSIVE'
*.standby_file_management='AUTO'
*.fal_server='orcl'
*.log_archive_config='DG_CONFIG=(orcl,orcls)'
*.log_archive_dest_1='LOCATION=+RECO VALID_FOR=(ALL_LOGFILES,ALL_ROLES) DB_UNIQUE_NAME=orcls'
*.log_archive_dest_2='SERVICE=orcl AFFIRM SYNC VALID_FOR=(ONLINE_LOGFILES,PRIMARY_ROLE) DB_UNIQUE_NAME=orcl'
*.log_archive_dest_state_2='DEFER'
*.log_archive_format='%t_%s_%r.arc'
*.dg_broker_start=TRUE
*.undo_tablespace='UNDOTBS1'
*.open_cursors=300
*.db_create_file_dest='+DATA'
*.db_create_online_log_dest_1='+DATA'
*.db_recovery_file_dest='+FRA'
*.db_recovery_file_dest_size=25000m
EOF

echo "orcls:/u01/app/oracle/product/26ai/db_1:N" | sudo tee -a /etc/oratab

sudo -u oracle bash -c '
export ORACLE_HOME=/u01/app/oracle/product/26ai/db_1
export ORACLE_SID=orcls
sqlplus / as sysdba <<SQL
STARTUP NOMOUNT PFILE=/u01/app/oracle/product/26ai/db_1/dbs/initorcls.ora;
EXIT
SQL
'

ALTER SYSTEM SET db_create_file_dest='+DATA' SCOPE=BOTH;
ALTER DATABASE ADD STANDBY LOGFILE THREAD 1 ('+DATA') SIZE 1024M;
-- repeat (online log groups + 1) times

ALTER DATABASE RECOVER MANAGED STANDBY DATABASE CANCEL;
ALTER SYSTEM SET standby_file_management=MANUAL SCOPE=BOTH;
-- DROP STANDBY LOGFILE GROUP for each group# in v$standby_log;
ALTER SYSTEM SET db_create_file_dest='+DATA' SCOPE=BOTH;
ALTER SYSTEM SET standby_file_management=AUTO SCOPE=BOTH;
ALTER DATABASE ADD STANDBY LOGFILE THREAD 1 ('+DATA') SIZE 1024M;
-- repeat (online groups + 1) times; one member per group
ALTER DATABASE RECOVER MANAGED STANDBY DATABASE USING CURRENT LOGFILE DISCONNECT FROM SESSION;

# On oracdb2
sudo -u oracle bash -c '
. ~/.bash_profile
export ORACLE_SID=orcls
sqlplus / as sysdba <<SQL
SHUTDOWN IMMEDIATE;
STARTUP MOUNT;
ALTER SYSTEM SET db_flashback_retention_target=1440 SCOPE=BOTH;
ALTER DATABASE FLASHBACK ON;
ALTER DATABASE RECOVER MANAGED STANDBY DATABASE USING CURRENT LOGFILE DISCONNECT FROM SESSION;
EXIT
SQL'

sudo -u oracle bash -c '
. ~/.bash_profile
sqlplus / as sysdba <<SQL
ALTER SYSTEM SET LOG_ARCHIVE_DEST_STATE_2=ENABLE SCOPE=BOTH;
ALTER SYSTEM SWITCH LOGFILE;
ALTER SYSTEM ARCHIVE LOG CURRENT;
SELECT dest_id, status, error FROM v$archive_dest_status WHERE dest_id IN (1,2);
EXIT
SQL
'
# Expected: dest_id=2, STATUS=VALID, ERROR null.

sudo -u oracle sqlplus -s / as sysdba \
  <<<"SELECT database_role || ' | ' || open_mode FROM v\$database;"
# Expected: PRIMARY | READ WRITE

gcloud compute ssh oracdb2 --tunnel-through-iap --zone=us-west1-b

sudo -u oracle bash <<'BASH'
. ~/.bash_profile
export ORACLE_SID=orcls

sqlplus -s / as sysdba <<'SQL'
SELECT database_role || ' | ' || open_mode
FROM v$database;

SELECT process, status, sequence#
FROM v$managed_standby
WHERE process IN ('MRP0','RFS');

EXIT
SQL
BASH

sudo -u oracle bash -c '
. ~/.bash_profile
export ORACLE_SID=orcls
sqlplus / as sysdba <<SQL
ALTER DATABASE RECOVER MANAGED STANDBY DATABASE CANCEL;
ALTER DATABASE RECOVER MANAGED STANDBY DATABASE USING CURRENT LOGFILE DISCONNECT FROM SESSION;
EXIT
SQL'

sudo -u oracle bash -c '
export ORACLE_SID=orcls
sqlplus -s / as sysdba <<< "SHOW PARAMETER spfile;"
'

sudo -u oracle bash -c '
export GRID_HOME=/u01/app/26ai/grid
export ORACLE_HOME=/u01/app/oracle/product/26ai/db_1
export PATH=$ORACLE_HOME/bin:$GRID_HOME/bin:$PATH

srvctl add database \
  -db orcls \
  -dbname orcl \
  -oraclehome /u01/app/oracle/product/26ai/db_1 \
  -spfile <STANDBY_SPFILE_PATH> \
  -pwfile /u01/app/oracle/product/26ai/db_1/dbs/orapworcls \
  -role PHYSICAL_STANDBY \
  -startoption MOUNT \
  -stopoption IMMEDIATE \
  -diskgroup DATA,RECO,FRA

srvctl config database -db orcls
srvctl status database -db orcls
'

sudo -u oracle bash -c '
export GRID_HOME=/u01/app/26ai/grid
export ORACLE_HOME=/u01/app/oracle/product/26ai/db_1
export PATH=$ORACLE_HOME/bin:$GRID_HOME/bin:$PATH
srvctl config database -db orcl
srvctl modify database -db orcl -diskgroup DATA,RECO,FRA
srvctl config database -db orcl
'

sudo -u oracle bash -c '
export GRID_HOME=/u01/app/26ai/grid
export ORACLE_HOME=/u01/app/oracle/product/26ai/db_1
export PATH=$ORACLE_HOME/bin:$GRID_HOME/bin:$PATH

srvctl add service \
  -db orcls \
  -service orclapp \
  -pdb orclpdb \
  -role PRIMARY \
  -policy AUTOMATIC

srvctl config service -db orcls -service orclapp
'

sudo -u oracle bash -c '
export GRID_HOME=/u01/app/26ai/grid
export ORACLE_HOME=/u01/app/oracle/product/26ai/db_1
export PATH=$ORACLE_HOME/bin:$GRID_HOME/bin:$PATH
srvctl status database -db orcls
'

sudo -u oracle bash -c '
. ~/.bash_profile
sqlplus / as sysdba <<SQL
ALTER SYSTEM SET dg_broker_start=TRUE SCOPE=BOTH;
EXIT
SQL'

sudo -u oracle bash -c '
export ORACLE_HOME=/u01/app/oracle/product/26ai/db_1
export ORACLE_SID=orcl
export PATH=$ORACLE_HOME/bin:$PATH
dgmgrl /
'

DGMGRL> CREATE CONFIGURATION 'orcl_dg' AS
        PRIMARY DATABASE IS 'orcl' CONNECT IDENTIFIER IS orcl;
DGMGRL> ADD DATABASE 'orcls' AS CONNECT IDENTIFIER IS orcls;
DGMGRL> ENABLE CONFIGURATION;
DGMGRL> SHOW CONFIGURATION;
-- Expect: Configuration Status: SUCCESS, both members SUCCESS.

DGMGRL> VALIDATE DATABASE 'orcls';
DGMGRL> SHOW CONFIGURATION VERBOSE;

sudo -u oracle bash -c '
. ~/.bash_profile
sqlplus -s / as sysdba <<<"SELECT flashback_on FROM v\$database;"
'
# Expected on both hosts: YES

sudo -u oracle bash -c '
. ~/.bash_profile
export ORACLE_SID=orcl
sqlplus / as sysdba <<SQL
ALTER SYSTEM SET db_flashback_retention_target=1440 SCOPE=BOTH;
EXIT
SQL'

-- Transport mode and protection mode
DGMGRL> EDIT DATABASE 'orcl'  SET PROPERTY LogXptMode='SYNC';
DGMGRL> EDIT DATABASE 'orcls' SET PROPERTY LogXptMode='SYNC';
DGMGRL> EDIT CONFIGURATION SET PROTECTION MODE AS MaxAvailability;

-- FSFO targets (each side names the other)
DGMGRL> EDIT DATABASE 'orcl'  SET PROPERTY FastStartFailoverTarget = 'orcls';
DGMGRL> EDIT DATABASE 'orcls' SET PROPERTY FastStartFailoverTarget = 'orcl';

-- 30 s = default; lower for faster RTO but more sensitive to network blips
DGMGRL> EDIT CONFIGURATION SET PROPERTY FastStartFailoverThreshold = 30;
DGMGRL> EDIT CONFIGURATION SET PROPERTY FastStartFailoverAutoReinstate = TRUE;

DGMGRL> ENABLE FAST_START FAILOVER;
DGMGRL> SHOW FAST_START FAILOVER;
-- Expected: Threshold 30 seconds, Target orcls, Observer not yet registered.

# On oradg-obs, as root (use -el8 / -el9 if the Observer is on an older OL/RHEL)
sudo dnf install -y oracle-instantclient-release-el10
sudo dnf install -y oracle-instantclient-basic \
                    oracle-instantclient-sqlplus \
                    oracle-instantclient-tools

# Dedicated 'oracle' OS user (owns the wallet and the systemd unit)
sudo useradd -u 54321 -m oracle
sudo passwd -l oracle

# Oracle environment for the user
sudo mkdir -p /etc/oracle/network/admin
sudo chown -R oracle:oracle /etc/oracle
sudo -u oracle tee /home/oracle/.bash_profile >/dev/null <<'EOF'
export ORACLE_HOME=/usr/lib/oracle/26/client64
export LD_LIBRARY_PATH=$ORACLE_HOME/lib
export PATH=$ORACLE_HOME/bin:$PATH
export TNS_ADMIN=/etc/oracle/network/admin
EOF

# tnsnames.ora — must reach both DB hosts on TCP/1521
sudo tee /etc/oracle/network/admin/tnsnames.ora >/dev/null <<'EOF'
orcl =
  (DESCRIPTION =
  (ADDRESS = (PROTOCOL = TCP)(HOST = oracdb1)(PORT = 1521))
                (CONNECT_DATA = (SERVER = DEDICATED)(SERVICE_NAME = orcl)))
orcls =
  (DESCRIPTION =
  (ADDRESS = (PROTOCOL = TCP)(HOST = oracdb2)(PORT = 1521))
                (CONNECT_DATA = (SERVER = DEDICATED)(SERVICE_NAME = orcls)))
EOF
sudo chown oracle:oracle /etc/oracle/network/admin/tnsnames.ora

sudo -iu oracle bash <<'BASH'
mkdir -p $TNS_ADMIN/wallet
mkstore -wrl $TNS_ADMIN/wallet -create     # prompts for a wallet password — store in your secrets manager
mkstore -wrl $TNS_ADMIN/wallet -createCredential orcl  sys ChangeMe!1
mkstore -wrl $TNS_ADMIN/wallet -createCredential orcls sys ChangeMe!1
BASH

sudo tee /etc/oracle/network/admin/sqlnet.ora >/dev/null <<'EOF'
WALLET_LOCATION = (SOURCE = (METHOD = FILE) (METHOD_DATA = (DIRECTORY = /etc/oracle/network/admin/wallet)))
SQLNET.WALLET_OVERRIDE = TRUE
EOF
sudo chown oracle:oracle /etc/oracle/network/admin/sqlnet.ora
sudo chmod -R 0700 /etc/oracle/network/admin/wallet

sudo -iu oracle ls -l /etc/oracle/network/admin/wallet
# Expected: cwallet.sso and ewallet.p12

sudo -iu oracle bash <<'BASH'
sqlplus -L "/@orcl as sysdba" <<'SQL'
SELECT database_role FROM v$database;
EXIT
SQL
BASH

sudo -iu oracle bash <<'BASH'
sqlplus -L "/@orcls as sysdba" <<'SQL'
SELECT database_role FROM v$database;
EXIT
SQL
BASH

sudo -iu oracle dgmgrl /@orcl  'SHOW CONFIGURATION;'
sudo -iu oracle dgmgrl /@orcls 'SHOW CONFIGURATION;'

sudo -iu oracle orapki wallet create \
  -wallet /etc/oracle/network/admin/wallet \
  -auto_login
sudo -iu oracle ls -l /etc/oracle/network/admin/wallet
# Expected: cwallet.sso and ewallet.p12

sudo tee /etc/systemd/system/dgmgrl-observer.service >/dev/null <<'EOF'
[Unit]
Description=Oracle Data Guard Fast-Start Failover Observer
After=network-online.target
Wants=network-online.target

[Service]
Type=simple
User=oracle
Group=oracle
Environment=ORACLE_HOME=/usr/lib/oracle/26/client64
Environment=LD_LIBRARY_PATH=/usr/lib/oracle/26/client64/lib
Environment=TNS_ADMIN=/etc/oracle/network/admin
Environment=PATH=/usr/lib/oracle/26/client64/bin:/usr/bin:/bin
ExecStart=/usr/lib/oracle/26/client64/bin/dgmgrl -silent /@orcl "START OBSERVER FILE IS '/var/lib/oracle/dgmgrl-observer.dat'"
Restart=always
RestartSec=5

[Install]
WantedBy=multi-user.target
EOF

sudo install -d -o oracle -g oracle -m 0755 /var/lib/oracle
sudo install -o oracle -g oracle -m 0640 /dev/null /var/log/dgmgrl-observer.log

sudo tee /etc/logrotate.d/dgmgrl-observer >/dev/null <<'EOF'
/var/log/dgmgrl-observer.log {
    weekly
    rotate 8
    compress delaycompress missingok notifempty
    create 0640 oracle oracle
    copytruncate
}
EOF

sudo systemctl daemon-reload && sudo systemctl enable --now dgmgrl-observer.service
sudo systemctl status dgmgrl-observer.service

DGMGRL> SHOW FAST_START FAILOVER;
DGMGRL> SHOW CONFIGURATION;       -- Configuration Status: SUCCESS, FSFO: ENABLED

DGMGRL> VALIDATE DATABASE 'orcls';
DGMGRL> SWITCHOVER TO 'orcls';
DGMGRL> SHOW CONFIGURATION;
DGMGRL> SWITCHOVER TO 'orcl';        -- restore topology
